Water EC Sensor for Accurate Detection of Electric Conductivity in 0-20000us/cm Range

Ask Lasest Price
Brand Name :	BGT
Model Number :	BGT-WEC(D)
Price :	$109.60 - $120.30/sets

Add to Cart

Product Details
Company Profile

Water EC Sensor for Accurate Detection of Electric Conductivity in 0-20000us/cm Range

Please Attention

Beijing Guoxinhuayuan Technology Co.,Ltd OFFER YOU:

1.Factory direct price.
2.Nice quality.
3.Small order is welcome.
4.Online payment.
5.Refund money in case of bad quality.
6.Sample offered but you need to pay it.
7.1 year free repair for quality warranty.

Product Description

0-20000us/cm range RS485 modbus 0-2V 4-20mA output electrical conductivity stainless steel ec probe sensor transmitter

BGT 5V DC power supply 0-3V output Water Analyzer Water quality EC conductivity Sensor Detector Probe transmitter

BGT-WEC conductivity sensor has high stability and sensitivity. It can measure EC, salinity and TDS simultaneously. Internal or external temperature sensors can be used for conductivity temperature compensation, which is suitable for industrial, electric power, agriculture, medicine, food, scientific research, environmental protection and other fields. The sensor has the following
features:
（1）High cost performance, simultaneous measurement of EC, salinity, TDS.

（2）Conductivity can be compensated for temperature.

（3）It can be used for conductivity of water fertilizer integrated solution and other nutrient solution and matrix.

（4）Optional stainless
steel electrode or ABS plastic electrode.

（5）The electrode is completely sealed and can be directly put into water for long-term
dynamic detection.

（6）High precision, quick response, good interchangeability, reliable performance.

（7）Complete protection
circuit and a variety of signal output interface.

Specification

Technical Specification
Signal Output Type	Voltage output 0-2V （Output Impedance ≈ 0Ω）	Current Output 4-20mA （Load resistance<500ohm）	RS485 Modbus protocol
Supply Voltage	3.9-30V/DC	12-30V/DC	3.9-30V/DC
Static Power	10mA@24V DC	30mA@24V DC (Current Output Channel 20mA)	10mA@24V DC
Conductivity range	Range：0-20000us/cm Resolution ratio：0-10000us/cm 10us/cm, 100000-20000us/cm 50us/cm Accuracy：0-10000us/cm ±3%; 10000-20000us/cm ±5%
Conductivity temperature compensation	Built-in temperature compensation sensor， 0-50℃
Temperature measurement range	Range：-40~80℃，Resolution ratio：0.1℃，Accuracy：±0.5℃
IP Grade	Conductivity electrode: IP68, long-term use in immersed water Transmitter body: IP67, splash proof
Operating Ambient Temperature	-40~85℃
Default Cable Length	Power and communication cables:2m(Customized) Electrode cable:5m
Connection	Pre-installed cold pressing terminal
Size	Thread installation of conductivity electrode：1/2"NPT thread Sensor body：1287042mm
Product Size	65mm46mm28.5mm

ISO14001

CE

ISO9001
